Chassis
9,600# GVWR • 16,000# GCWR • TBD# UVW • TBD# OCCC • 3500 Chevrolet Express RWD • Vortec V8 6.0L, 323 HP @ 4600 RPM, 373 lbs Torque @ 4400 RPM, 6 Speed Automatic w/Overdrive • Traveling Seating Capacity-5 • Sleeping Capacity- 2 • 155" Wheelbase • 50 State Emissions • 31 Gallon Fuel Tank • Radial Tires • 145 Amp Alternator • Aluminum Wheels • Full Size Spare Tire at Rear Bumper Locations • Maintenance Free Chassis Battery- Lead Acid 770 CCA • Maintenance Free House Batteries (2)- AGM Group 24 w/Manual Disconnect • Body Insulation • Class IV Hitch- 400/4000 Weight Carrying- 1000/10,000 with Weight Distributing Hitch Fill • 72" Interior Headroom • 72" Interior Width at Floor • 20'4" Exterior Length • 79.4" Exterior Width • 109" Exterior Height at Vent.
Driver Compartment
Privacy Blackout Curtain (Wrap Around) • AM/FM CD Stereo w/CD/Auxiliary Input (4 Speakers) • Dash Trim Kit • Driver/Passenger Floor Mat • Emergency Auxiliary Start Solenoid • Rear Window Defogger- Electric • Driver Seat, 6 Way Power w/Swivel • Passenger Seat Manual w/Swivel.
Exterior
White Body • Exterior Body Kit • Fog Lamps • Airstream Lettering • Avenue Medallions • Mid-Body Pin Stripe • Power Patio Awning • Tinted Glass (Except Cab Area).
Interior
Flush Mount Cabinet Doors • Radius Overhead Doors • Recessed Hardware • Side/Rear Curtains • Vinyl Flooring • Interior Ceiling Vinyl Padded.
Lounge
Power Rear Sofa- Ultraleather, 72" x 76" Sleeping Area • Ultraleather Driver/Co Pilot Seating • Pedestal Mount Table • Overhead Lockers- RS, CS & Rear.
Galley
Corian Countertop w/Backsplash • 3 Burner Cooktop & Sink Combo • Filtered Galley Faucet • Waste Basket w/Slide Out.
Bathroom
Stand Up Enclosed Wet Bath w/Macerator Toilet & Sink- Includes Portal Window in Bath Door & Shower Curtain Inside Bath • LED Shower Lights (2) Towel Bar • Clothes Line/Hanger- Retractable.
Appliances
Microwave • 3.1 Cu.Ft Refrigerator (12V/110V) w/Aluminum Insert • 13,500 BTU Air Conditioner w/Wall Thermostat • Omni Directional TV Antenna • Cable TV Hook Ups, RS Rear Exterior • Smoke, Carbon Monoxide & LPG Detectors • Satellite Dish/Receiver Prewire • 19" TV/DVD & Headphone Jacks (2) • Audio/Video Port (RS) • 16,000 BTU Furnace • 6 Gallon LP/Electric Water Heater • Rearview Camera w/Rearview Mirror Monitor.
Electrical
LED Lighting • LED Directional Reading Lights • Probeless Tank Monitoring System • Maxx Air Roof Vent w/Built in Thermostat (Exhaust Only) • 12V & 120V Exterior Outlets at Patio • Gasoline Generator 2.8KW Quiet Microlite w/Remote Start • 30 Amp Service w/Energy Management System & Detachable Power Cord • Solar Panel Prewire • Exterior TV Hook Up at Patio • Patio Light • Bath Exhaust Fan • Converter/Inverter- 45 Amp Charger/ 750 Watt Inverter • Water Pump • Antenna Booster.
Systems
9.9 Gallon LPG Tank w/Remote Fill • 33 Gallon Fresh Water Tank w/Drain- 12V Heated • 21 Gallon Grey Water Tank- 12 V Heated • 10 Gallon Black Water Tank w/Flush- 12V Heated • Macerator Pump Discharge System w/ 20' Hose & Fittings • Fire Extinguisher • Exterior Shower • City Water Hook-Up • Gravity Fresh Water.
