Named for its ability to change right along with its passenger’s needs, the 170 Versatile combines convenience, comfort, efficiency and value all into one stylish package. Ideal for the active family, the 170 Versatile offers all the amenities of a larger motorhome with the added benefit of driveability, parking ease and fuel efficiency.
Specifications
Specifications| Starting MSRP | $89,518 USD $96,317 CDN |
|---|
| Base Model | Chevrolet Express 2500 |
|---|
| Seating Capacity | Seats 6 |
|---|
| Sleeping Capacity | Sleeps 2-4 in front singles & rear double bed |
|---|
| Fuel Type | Gasoline |
|---|
| Exterior Length | 18' 9" 5,720 mm |
|---|
| Exterior Width (without mirrors) | 6' 7" 2,007 mm |
|---|
| Interior Aisle Width | 30" 760 mm |
|---|
| Exterior Height (with roof AC) | 8' 9" 2,660 mm |
|---|
| Interior Standing Height | 6' 1" 1,855 mm |
|---|
| Wheelbase | 135" 3,430 mm |
|---|
| Gross Vehicle Weight Rating | 8,600 lbs. 3,900 kg |
|---|
| Occupant & Cargo Carrying Capacity 1 | 1,250 lbs. 500 kg |
|---|
| Gross Combined Weight Rating 2 | 13,000 lbs. 5,897 kg |
|---|
| Towing – Tow Weight 3 | 5,400 lbs. 2,450 kg |
|---|
| Towing – Tongue Weight 4 | 1,000 lbs. 450 kg |
|---|
| Fresh Water Capacity | 20 U.S. gal. 75 L |
|---|
| Black Holding Tank Capacity | 8 U.S. gal. 30 L |
|---|
| Gray Holding Tank Capacity | 23 U.S. gal. 85 L |
|---|
| Storage Capacity (with options) | 33 cu. ft. (49 cu. ft.) 930L / 33 cu. ft. (1,400L / 49 cu. ft.) |
|---|
| Rear Double Bed Size (width x length) | 73" x 50" 1,855 mm x 1,260 mm |
|---|
| Front Single Bed Size – Right (width x length) | 22” x 74” 560 mm x 1,880 mm |
|---|
| Front Single Bed Size – Left (width x length) | 22” x 58” 560 mm x 1,470 mm |
|---|
RV Warranty Six year unlimited mileage/km, Peace of Mind motorhome warranty, covering the manufacture of the motorhome, appliances, electronics, plumbing and EcoTrek™ batteries. Original manufactures warranty on all appliances will be applied first. Warranty excludes the complete chassis and AGM batteries which have a normal one year manufacturer’s warranty. | Chassis Warranty Three year/36,000 mile or 60,000 km limited "bumper to bumper" warranty and Five year/100,000 mile or 160,000 km limited powertrain warranty as offered by General Motors. Refer to chassis manufacturers’ website for details. | - Allowance for weight of occupants, water, propane and cargo. Reduce by weight of optional equipment.
- GCWR includes total weight of vehicle, trailer, equipment, fuel, water, propane, cargo, driver and passengers.
- Maximum towable weight with driver and fuel only. This weight reduced by weight of optional equipment, water, propane, cargo and/or passengers.
- A weight distributing hitch is required for tongue weights over 200 Kg/400 lbs.
|
Coach Features| Air Conditioner | Standard 110 V, 10,200 BTU |
|---|
| Armoire | Optional Removable armoire (interchangeable with right lounge seat) |
|---|
| Awning | Standard 9’ 10” power awning 3,000 mm power awning |
|---|
| Bathroom – Temporarily Enclosed | Standard Temporarily enclosed with bi-fold doors |
|---|
| Batteries | Standard One 12V AGM, 1,200 W |
|---|
| Batteries (2 Additional) | Optional 2 additional 200 Amp hour AGM batteries - 6 Volt |
|---|
| Dinette | Standard |
|---|
| Detectors | Standard Smoke, propane & CO |
|---|
| DVD Player | Standard DVD with 6 speaker home theatre surround sound system |
|---|
| EcoTrek 200 | Optional EcoTrek 200 Lithium Power Modules |
|---|
| EcoTrek 400 | Optional EcoTrek 400 Lithium Power Modules |
|---|
| External Power Connection | Standard 110V/30AMP |
|---|
| Furnace | Standard Propane automatic, 16,000 BTU |
|---|
| Generator | Optional Conventional gasoline with remote start, Onan 2.8 kW |
|---|
| Generator – Under Hood | Optional 12V, 3,500W, includes two extra 6V batteries (B2 option), 2,500W inverter |
|---|
| GoSun Solar Cooker | Optional GO SUN Solar Oven |
|---|
| Home Theater System | Standard With 5.1 surround sound & dual center speakers with DVD, CD, AM/FM radio, dual use rear speakers |
|---|
| Mattress – Folding (Single, One Mattress) | Optional Single folding for 1st & 2nd row seats |
|---|
| Mattress – Folding (Two single mattresses) | Optional Two folding mattresses for front sleeping 1st & 2nd row seats |
|---|
| Microwave Oven | Standard 110V, 20L/0.7 cu. ft., 700W |
|---|
| Monitor Panel | Standard Water, propane & battery charge levels, battery disconnect & generator hour meter |
|---|
| Permanent Cabinet | Optional Permanent cabinet includes hanging for clothes and shelving (replaces driver side second row lounge seat) |
|---|
| Portable Solar Cell | Optional Portable solar cell 200 watts |
|---|
| Power Converter with Charger | Standard 110V/12 V, 3 step 45 AMP charger |
|---|
| Power Inverter | Standard 12/110V, 750W |
|---|
| Propane Tank | Standard 38L/10 U.S. gal., 45lbs. |
|---|
| Rear power sofa – Forward facing | Standard |
|---|
| “Halo” leather rear power sofa | Standard "Halo" leather for rear power sofa |
|---|
| Refrigerator | Standard 12V/110V propane, 3.0 cu. ft. with auto source selection |
|---|
| Screen Package | Optional Screens for side & rear cargo door openings (includes side door windows) |
|---|
| Second Row Captain Seat | Optional Passenger side captain's seat in second row (replaces lounge seat; n/a with AM option) |
|---|
| Sewage Disposal System | Standard 12V macerator sewage pump |
|---|
| Solar Panels 200W | Optional Solar panel inc. 200W solar panel and charge control |
|---|
| Storage Compartments (Exterior) | Standard One below floor |
|---|
| Stove – Propane | Standard Propane; two burner, recessed with flush cover |
|---|
| Television | Optional 22" flat screen HDTV on rotating bracket |
|---|
| Volt Start | Optional Volt Start Autostart Battery Protection Technology |
|---|
| Water Heater | Standard Propane with bypass, 23L/6 U.S. gal., 12,000BTU |
|---|
| Water System | Standard On-demand 12V with water pump |
|---|
Chassis Features| Battery | Standard 600 AMP |
|---|
| Camera – Rearview Backup | Standard |
|---|
| Climate Control | Standard |
|---|
| Continental Spare Tire Carrier | Optional Continental spare tire kit with proprietary effort reduction system (receiver mounted in front of driver side rear door) |
|---|
| Cooling – Transmission Oil | Standard External |
|---|
| Cruise Control | Standard |
|---|
| Engine | Standard 4.8L SFI gas V8 |
|---|
| Fender Flares | Optional Custom wheel flare moldings (All 4 wheels) |
|---|
| Headlights – Automatic On/Off | Standard |
|---|
| Mirrors – Exterior | Standard Power, heated with convex |
|---|
| OnStar® | Optional GM OnStar audio system including DVD/GPS (Must Code) |
|---|
| Power | Standard 285HP 213kW/285HP |
|---|
| Radio | Standard Audio system with navigation, AM/FM stereo with MP3 compatible CD/DVD player & navigation, USB port, seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS), speed-compensated volume & TheftLock® |
|---|
| Receiver | Standard Class IV |
|---|
| Stability Program | Standard Adaptive (accounts for load) |
|---|
| Theft Deterrent System | Standard |
|---|
| Tilt Steering | Standard |
|---|
| Tire Storage | Standard Rear storage area |
|---|
| Tires | Standard LT245/75R16E black wall |
|---|
| Torque | Standard 398 Nm/295 lb.-ft. |
|---|
| Transmission | Standard Automatic 6-speed heavy duty |
|---|
| Wheels – Aluminum | Optional 16” aluminum polished with steel spare |
|---|
| Window Operation – Power | Standard Power; front doors only |
|---|
| Wiring Harness for Towing | Standard 4 way & 7 way connector |
|---|
| CG Paint Package (Charcoal) | Optional Charcoal paint |
|---|
| SE Paint Package (Silver Ice) | Optional Silver Ice paint |
|---|
| Custom Paint Color | Optional Custom paint order - owner provides paint codes |
|---|
| WH Paint Package (Bright White) | Standard |
|---|
Specifications are subject to change without notification.
|
