Setting a new standard in a mid-sized package, the Ranger RT offers all the luxuries of a fully-equipped camper van but with the added benefits of impressive fuel efficiency from a smaller engine and lighter chassis
Specifications
Specifications
|
Starting MSRP
|
$78,988 USD
$81,822 CDN
|
|
Base Model
|
2500 Chevrolet Express
|
|
Seating Capacity
|
Seats 4
|
|
Sleeping Capacity
|
Sleeps 2 in rear twins or king-size bed
|
|
Fuel Type
|
Gasoline
|
|
Exterior Length
|
20' 5"
6,220 mm
|
|
Exterior Width (without mirrors)
|
6' 7"
2,007 mm
|
|
Interior Aisle Width
|
26"
660 mm
|
|
Exterior Height (with roof AC)
|
8' 9"
2,660 mm
|
|
Interior Standing Height
|
6' 1"
1,855 mm
|
|
Wheelbase
|
155"
3,944 mm
|
|
Gross Vehicle Weight Rating
|
8,600 lbs.
3,900 kg
|
|
Occupant & Cargo Carrying Capacity 1
|
1,700 lbs.
750 kg
|
|
Gross Combined Weight Rating 2
|
13,000 lbs.
5,897 kg
|
|
Towing – Tow Weight 3
- optional feature
|
8,200 lbs.
3,719 kg
|
|
Towing – Tongue Weight 4
- optional feature
|
1,000 lbs
454 kg
|
|
Fresh Water Capacity
|
18 U.S. gal.
65 L
|
|
Black Holding Tank Capacity
|
10 U.S. gal.
40 L
|
|
Gray Holding Tank Capacity
|
23 U.S. gal.
85 L
|
|
Storage Capacity (with options)
|
49 cu. ft.
1,390 L
|
|
Rear King Bed Size (width x length)
|
73” x 76”
1,855 mm x 1,930 mm
|
|
Rear Twin Bed Size – Right (width x length)
|
27” x 72”
690 mm x 1,830 mm
|
|
Rear Twin Bed Size – Left (width x length)
|
27” x 76”
690 mm x 1,930 mm
|
RV Warranty
5 year unlimited mileage/km, RV limited warranty covering the manufacture of the motorhome only (excludes chassis).
|
Chassis Warranty
3 year/36,000 mile or 60,000 km limited "bumper to bumper" warranty and 5 year/100,000 mile or 160,000 km limited powertrain warranty as offered by General Motors. Refer to chassis manufacturers’ website for details.
|
- Allowance for weight of occupants, water, propane and cargo. Reduce by weight of optional equipment.
- GCWR includes total weight of vehicle, trailer, equipment, fuel, water, propane, cargo, driver and passengers.
- Maximum towable weight with driver and fuel only. This weight reduced by weight of optional equipment, water, propane, cargo and/or passengers.
- A weight distributing hitch is required for tongue weights over 200 Kg/400 lbs.
|
Coach Features
|
Air Conditioner |
Standard
110V, 10,200BTU roof mount
|
|
Awning |
Optional
11’ 6” box awning
3,500 mm box awning
|
|
Bathroom – Permanently Enclosed |
Standard
Permanently enclosed with sink & shower
|
|
Batteries |
Standard
Two 6V AGM, 2,400 W
|
|
Batteries (2 Additional) |
Optional
Two additional 200AMP hour 6V AGM batteries, (Must code engine upgrade option - C8)
|
|
Detectors |
Standard
Smoke, propane & CO
|
|
External Power Connection |
Standard
110V
|
|
Generator |
Optional
Conventional gasoline with remote start, 2.8 kW with "Continental spare tire kit included" (not available with Under hood generator)
|
|
Generator – Under Hood |
Optional
12V, 3,500W, includes (2 extra 6V AGM batteries - B4 option) (not available with Conventional gasoline generator) (Must code engine upgrade option - C8)
|
|
Microwave Oven |
Standard
110V, 20 L/0.7 cu. ft., 700W
|
|
Monitor Panel |
Standard
Water, propane (with option) & battery charge levels, battery disconnect & generator hour meter (with option)
|
|
Power Converter with Charger |
Standard
110V, 12 V, 3 step 45 AMP charger
|
|
Power Inverter |
Standard
12/110 V, 1,250W (with 4 receptacles)
|
|
Propane Tank |
Optional
25L/7 U.S. gal., 30 lbs. includes Furnace - Propane automatic, 16,000 BTU, Stove - two burner recessed with flush cover & built-in igniter
|
|
Rear Power Sofa With Fabric |
Standard
Power rear sofa
|
|
Refrigerator |
Standard
12V/110V compressor driven with thermostat, 3.1 cu. ft.
|
|
Screen Package |
Optional
Side door windows, side door & rear door
|
|
Sewage Disposal System |
Standard
Gravity
|
|
Solar Charging System |
Optional
Solar panel inc. 225W solar panel and charge controller
|
|
Storage Compartments (Exterior) |
Standard
Two below floor
|
|
Stove – Electric |
Standard
110V flush mounted inductive cooktop
|
|
TV/DVD |
Optional
22” HD flat screen on rotating bracket with remote
|
|
Water Heater |
Standard
110V, 9 L/2.5 U.S. gal
|
|
Water System |
Standard
On-demand 12 V with water pump
|
Chassis Features
|
Airbag |
Standard
Driver & passenger (with passenger on/off switch)
|
|
Alternator |
Standard
145 AMP
|
|
Anti-Lock Brakes (ABS) |
Standard
Four wheel disc
|
|
Axle – Rear |
Standard
3.42 (USA) ratio
|
|
Battery |
Standard
600 AMP
|
|
Climate Control |
Standard
|
|
Continental Spare Tire Carrier |
Optional
Continental spare tire kit (receiver mounted in front of driver side rear door)
|
|
Cooling – Transmission Oil |
Standard
External
|
|
Cruise Control |
Standard
|
|
Engine |
Standard
4.8L SFI gas V8
|
|
Engine Upgrade |
Optional
6.0L SFI gas V8
|
|
Headlights – Automatic On/Off |
Standard
|
|
Mirrors – Exterior |
Standard
Manual
|
|
OnStar® |
Optional
OnStar audio system including DVD/GPS - (Must code engine upgrade option - C8)
|
|
Power |
Standard
285HP
213kW/285HP
|
|
Radio |
Standard
In-dash AM/FM with CD player
|
|
Receiver |
Optional
Trailer hitch and wiring (Must select engine upgrade option - C8)
|
|
Stability Program |
Standard
|
|
Theft Deterrent System |
Standard
|
|
Tilt Steering |
Standard
|
|
Tire Storage |
Standard
Underslung at rear
|
|
Tires |
Standard
LT245/75R16E black wall
|
|
Torque |
Standard
398 Nm/295 lb.-ft.
|
|
Trailer Hitch & Wiring |
Optional
4 and 7 way connectors - (Must select engine upgrade option - C8)
|
|
Transmission |
Standard
Automatic 6-speed heavy duty
|
|
Window Operation – Power |
Standard
Power; front doors only
|
Specifications are subject to change without notification.
